| Applicable Optical Fiber Types | SM(G.652/G.657)MM(G.651)DS(G.653)NZDS(G.655)EDF,BIF/UBIF(G.652/G.657),MM(G.651).DS(G.653),NZDS(G.655) |
| Motor Number | Six motors |
| Applicable Optical Fiber Types | SM (G.652/G.657), MM(G.651), DS(G.653), NZDS(G.655), EDF, BIF/UBIF, G657B3-1 |
| Applicable Optical Fiber Core Number | Single Core |
| Applicable Optical Fiber Diameter | Cladding Diameter : 80-150μm Coating diamete r: 125~1000μm |
| Fusion Splice Mode | Prestore:8 Groups User Define : 792groups |
| Average Fusion Splice Loss | 0.02dB(SM), 0.01dB(MM), 0.04dB(DS) 0.04dB (NZDS) |
| Return Loss | Better than 60db |
| Fusion Splice Duration Time | 9sec (Typical Parameter) / 6sec (FastMode) |
| Loss Estimation of Fusion Splice | Exist |
| Tension Test | 2N or more (optional) |
| Monitor | 4.3 - inch LCD Screen, |
| Language | 10 kinds (Chinese, English, French, Spanish, Russian, German, Polish, Italian, Portuguese, Thai) |
| Optical Fiber Magnification Times | X / Y : 180 times, X or Y : 350 times |
| Power Supply | 6800 mAh Lithium battery, 13.5V / 5A Power Adapter |
| Battery | Typically Works More than 280 Times (Welding / Heating) ,Charing Time 2 Hours, Rechargeable for 500 Times |
| Splice Results Storage | 10000 Records splice image (opitional) |
| Data Interface | USB 2.0 |
| Operating Environment | Elevation : 0~5000m. Relative Humiditv : 0~95%, Temperature : -20°C~55°C, Maximum Wind Speed : 15m/s |
| Storage Environment | Relative Humidity : 0~95% Temperature : -40°C~80°C (Except Battery), Temperature : - 10°C~40°C (Battery） |
| Size | 167Dx 154Wx 141H(mm) |
| Weight | 1.76kg（without battery），2.17kg(with battery) |
| Fiber holder | Multi-functional fiber holder (250um, 900um，2~3mm） SC/LC/FC fiber holder (optional) |
| Applicable Optical Fiber Cable Diameter | 60mm, 50mm, 45mm, 40mm ,25mm(FP-03) |
| Applicable Sleeve Length | Fusion-Protection Sleeves 9s Fast Heating (Customizable） |
| Heating Temperature | 10°C-260°C (Customizable) |
